MUSIC HALL MPA 15.3 MM/MC PHONO AMP
Pay as per month with Paybright
NO ONE CREATES TURNTABLES AND PHONO AMPS LIKE MUSIC HALL, AND THE PA15.3 IS NO EXCEPTION.
The pa15.3 is fully adjustable for gain and loading allowing you to really dial in and maximize the performance of your cartridge.
A real stand-out product that provides the functionality and sound quality of units easily costing 5 times the pa15.3’s modest price point.
- phono MM & MC capability
- adjustable gain & cartridge loading
- superior low noise design
- excellent RIAA linearity
- subsonic filter on/off
- gold plated RCA connectors
- outboard power supply / worldwide compatibility
THD <0,001% at SmV at 40dB gain, <0.005% at lmV at 60dB gain Gain Gain, 40dB / 43dB / 60dB /63dB Input Impedance 10ohm / 100 ohm / 1kohm / 47kohm Input Capacitance lOOpF / 200 pF / 320pF / 420pF Noise Floor 92dBV (A weighted), 87dBV (20Hz·20kHz) Max. Output Voltage 10Vrms (THD <1%) RIAA-Equalization Curve Accuracy Max. O.5dB / 20Hz – 20KHz Outboard Power Supply 18V/500m DC , suitable for your country’s mains supply Crosstalk >98dB at 5mV, 10kHz , 40dB gain Power Consumption 30mA DC Dimensions (H x W x D) 57mm x 100mm x 170mm Weight (without Power Supply) 550g
