ADAM T8V ACTIVE SPEAKER (SINGLE)
$419.00
Product Details
Best-in-class characteristics and sound performance
With incredible quality, matched with an equally impressive affordable price point, the award-winning ADAM Audio T8V is the most powerful and impressive model from the T Series range.
Meticulously designed to meet ADAM Audio’s high standards of durability and high performance, the T8V is perfect for those who have always wanted to work with monitors equipped with 8” drivers, but have been deterred through budgetary reasons.
Like the T5V and T7V models, the T8V is powered with Class D amplification and uses the precision U-Art tweeter with the HPS-waveguide system. What makes the T8V stand out from its counterparts, is its more pronounced sound and power, thanks in part to its larger, polypropylene 8” woofer, and 70 watt amplifier.
The ADAM Audio T8V pair can reach SPLS of 118 dBs, in addition to going as low as 33 Hz, which makes it particularly suitable for those making bass-heavy music.
With great headroom, high-end detail and a large sweet spot, the T8V has enough quality to perform as a main monitor in most professional recording setups, in addition to being compact enough for home studio environments. Providing best-in-class characteristics with a non-fatiguing sound at only 9.8kg, the T8V is one of the best sounding 8” monitors around.
Specifications in detail
General Data
- Panel Rear
- Max. Power Consumption 150 W
- Weight 21.6 lb (9.8 kg)
- Height x Width x Depth 15.8″ x 9.8″ x 13.2″ (400 mm x 250 mm x 335 mm)
- Warranty 5 years (2 years warranty plus 3 years optional with product registration)
- Delivery Contents Power cord, Quick Start Guide
Audio Input Connectors
- Analog XLR / RCA
- Input Impedance 10 kOhm / 20 kOhm
Amplification
- Woofer:
- Amplifier Type PWM
- Amp. Power RMS 70 W
- Tweeter:
- Amplifier Type PWM
- Amp. Power RMS 20 W
Acoustics
- Frequency Response 33 Hz – 25 kHz (-6 dB)
- THD > 80 Hz 0.5 %
- Max. SPL per pair at 1 m ≥118 dB
- Crossover Frequency 2.6 kHz
Drivers
- Woofer:
- Basket Diameter 8″
- Voice Coil Diameter 1″
- Cone Material Polypropylene
- Tweeter:
- Type U-ART
- Diaphragm Area 4 inch² (2420 mm²)
- Equiv. Diaphragm Diameter 1.9″ (48 mm)
- Velocity Transform Ratio 4 to 1
- Diaphragm Weight 0.17 g
- Waveguide HPS
Control Options
- Input Sensitivity -10 to +4 dB
- Gain Yes
- High Shelf EQ > 5 kHz -2 dB, 0 dB, +2 dB
- Low Shelf EQ < 300 Hz -2 dB, 0 dB, +2 dB
