LEBEN CS-600X INTEGRATED AMPLIFIER

$12,995.00

Quantity

Product Details

SMALL AND POWERFUL TUBE EL84 (MADE BY "SOVTEK" / RUSSIA)

CS-300X(S) is equipped with SOVTEK Tube EL-84 which has been welknown by audiophiles for its high sound quality against its small size.
A high input sensitivity of EL84 does not require a complicated circuit and accordingly, it can create a low distortion output signal.



HIGHEST-END AUDIO GRADE COMPONENTS

  • RESISTORS: Precision Industrial Grade +/-1%
  • FIRST-STAGE BY-PASS CONDENSOR: An ultimate audio condensor "OS Condensor" developped by "SANYO"
  • LAST-STAGE BY-PASS CONDENSOR: "Fine-Gold" by "NICHICON"
  • JOINT CONDENSOR: "Metalized Polypropylene Condensor" with "Mesh-Shielding".
  • NF OVERSHOOT PREVENTION CONDENSOR: Ceramic Conderser.
  • CATHODE RESISTOR: 4W type.(Instead of 3W type)
  • OUTPUT TRANSFORMER: Newly developped Transformer with wider range for high frequency.
  • WBT type binding post.(From April/05 delivery onward)/li

FIVE INPUTS
CS-300X(S) IS EQUIPPED WITH 5 LINE INPUTS PLUS TAPE MONITOR.



OTHER LUXURIOUS PARTS

  • Tube Shield-Base: 24K gold plated.
  • SIDE-WOOD PANEL: Canadian White-Ash".

FULL FUNCTIONS FOR INTEGRATED AMP.

  1. TAPE MONITOR.
  2. HEADPHONE OUTPUT.
  3. BASS BOOST SWITCH
  4. SPEAKER/HEADPHONE SELECTOR.
  5. VARIABLE OUTPUT IMPEDANCE: 4/6/8 OHMS.
  6. Operation Lamp Indicator.
  7. On-Switch Power Indicator LED.

CS-300X(S) SPECIFICATIONS

TUBES EQUIPPED EL84(SOVTEK) X 4
12AX7A(Sovtek) X 2
OUTPUT POWER 15W X 2
FREQUENCY RESPONSE 15Hz - 100KHz (-2 dB)
DISTORTION 0.7%(10W)
INPUT SENSITIVITY 600mV
INPUT IMPEDANCE 100K Ohms
OUTPUT IMPEDANCE 4/6/8 Ohms (Selectable)
POWER CONSUMPTION 82W
WEIGHT 10.5 Kgs.
DIMENSIONS 360 (W) X 270 (D) X 140 (H) mm
ATTACHMENT Detachable AC Power Cable x 1
