Construction principle | Acoustically optimized drive shape Base carrier plate 25 mm and feet made of all-aluminum Resonance optimized and decoupled via special Teflon discs and silicone mixture Damper Height adjustment via threaded spikes, decoupled via special felt feet |
---|---|
Range | Convenient speed switching at the touch of a button 33.3, 45 rpm fine adjustment + or – possible at any time at the touch of a button |
Bearing | Ground stainless steel axle cast liner and cast bearing bottom floor again dampened and decoupled with Teflon discs. Special resonance-optimized material with polished ceramic ball |
Drive | Berger Lahr Synchronous Motor with Belt Drive Belt made of Nylon Silicone Mixture Microprocessor Controlled Electronics |
Turntable | Made of all aluminium 7 kg turntable thickness 35 mm CNC precision turned and polished by hand |
Turntable pad | Support mat made of felt 3mm Plexiglas pad |
Synchronization | 0.08 % (measured with Ortofon measuring computer) |
Electrical/Power Supply | 240 Volt 47-63 Herz 0.4 Amper Output 32 Volt 0.46 Amper maximum Switching power supply with IEC plug cable |
Weight | 19 kg weight without tonearm |
Weight | 19 kg |
---|---|
Size | 31 × 31 × 20 cm |
Material |
Aluminium |
Control |
Microcontroller M2 with quartz generator and fine adjustment |
Scope of delivery |
1 turntable Solid 111 metal |
