CALL FOR PRICING

The idea

… based on our previous experience with Woodpecker and Blackbird Turntables we have refined our applied concepts. The ability to handle two 12 inch tonearms was one of the principle design parameters along with simplifying the turntable setup and alignment procedures. We also focused on the visual perspective as well with evolutionary refinements in our form factor, fit and finish and presence. From a tonal standpoint the Firebird represents the pinnacle of the DFA product line, it is truly our new reference turntable.

The mission

… was not to simply modify the electronics used from the Woodpecker and Blackbird – that would have been to simple, no, instead we started from scratch with all new electronics. We developed a much more sophisticated type of hardware and completely rewrote our software, taking multi-motor-turntable operation to a never before seen level. Not to worry though, this new technology will also be integrated into our current Woodpecker and Blackbird tables, thus elevating their performance as well.

Running on three motors we chose the only geometrical configuration that really makes sense – the equilateral triangle. As we have already shown with the Blackbird, the positive effects of reduced drag force on the bearing is bettered by the triangle configuration as it also stabilizes the bearing/platter assembly by cancelling out all acting forces. All tendencies of gyration are effectively eliminated. Combined with our all new bearing with 80% reduced area of contact - which will also be fitted to the Woodpecker and Blackbird models - we achieve much lower friction causing less rumble and improving the wow & flutter even more …

The result

… timeless elegance paired with perfect measurements. Ease of use at a new level that improves upon the experience from our smaller models. Easier to set up as we also designed new feet that allow a much wider range of leveling capability along with improved sonics.  In addition we have also implemented and improved our well known built-in Protractor TT for setting up tonearms and cartridges. An all new and more refined armboard-design that makes assembly even easier than before with enhanced accuracy. You‘ll be amazed at how simple it is to achieve the best performance.

The sound

… pitch black background paired with pure dynamics, both macro and micro.  Power and stability meets neutrality. Whatever your choice of tonearm/cartridge is – the Firebird will reveal the most you can get out of it opening new horizons for your listening pleasure.

You will be completely confident that nothing is being held back. Sit back, relax, leave all discussions about the technical aspects behind you and just enjoy the music …

Get involved – more and more …

belt-drive turntable, 3 motors, 2 tonearms
quick-release system for tonearms/armboards
integrated Protractor for cartridge/tonearm alignment
dimensions: 560 mm x 460 mm x 160 mm
right arm-slot: 205 - 345 mm pivot-spindle (9 - 14 inch eff. length)
left arm-slot (optional): 205 - 300 mm pivot-spindle (9 - 12 inch eff. length)
weight: 23 kg (chassis), 29 kg (w/o tonearm)
warranty: 2 years (chassis and electronics), 5 years (bearing)
