ORTOFON - STYLUS 14

$93.00

Pay as per month with Paybright

Quantity

Product Details

Technical specifications

Frequency range: 20-22.000 Hz
Frequency response: - 20-20.000 Hz + 2 / - 2 dB
Tracking ability at 315Hz at recommended tracking force*): 70 µm
Compliance, dynamic, lateral: 25 µm/mN
Stylus type: Elliptical
Stylus tip radius: r/R 8/18 µm
*) Typical value

Equivalent stylus tip mass: 0.5 mg
Tracking force range: 1.0-1.5 g (10-15 mN)
Tracking force, recommended: 1.25 g (12.5 mN)
Tracking angle: 20°
Stylus colour:  Black
Recommended for TM 14U
