Rega Nd5 Moving Magnet Cartridge

Rega Nd5 Moving Magnet Cartridge

The all-new Rega Nd5 moving magnet cartridge was developed over 10 years to deliver next-level performance from moving magnet technology. The Nd range (patent pending) is a world first in using an ultra-high-powered Neodymium magnet, allowing a totally unique design. Each Nd5 is meticulously hand-made by Rega's skilled technicians in the UK. Available now at Vinyl Sound Canada.

Nd magnet technology

Often used in moving coil designs, including Rega's own, the Nd5 is believed to be the first moving magnet cartridge to use a Neodymium (Nd) N55 magnet, the world's most powerful commercially available magnet. This crucial component makes the unique design possible by delivering more power than standard bar-magnet designs.

Advanced generator and coils

The Nd5 uses brand-new generator geometry with perfect symmetry for accurate channel balance, and an optimised pole gap for superior linearity and cross-talk, providing a far wider soundstage than previous models. Miniaturised parallel coils are wound in house using 38-micron wire with just 1275 turns, producing a low-inductance, low-impedance generator for vastly improved high-frequency response.

Nude elliptical diamond stylus

The Nd5's stylus is a perfect elliptical nude diamond, a true ellipse created by an elliptical grinding process from polycrystalline manmade diamond, fitted to an aluminium cantilever. This nude profile provides exceptional tracking accuracy and extracts greater levels of detail from the vinyl surface than a bonded stylus. The complete assembly is housed in a zero-tolerance injection-moulded glass-filled polyphenylene sulphide (PPS) body, a lightweight, highly rigid material that reduces stress on the tonearm bearings and aids free movement, inspired by Rega's MC range. The Nd range is supplied in 100% recyclable packaging.

Factory-fitted options and rebuild scheme

The Nd5 is offered as a factory-fitted option on the multi-award-winning Rega Planar 3 and Planar 6 turntables, designed specifically with these models in mind to extract the very best from your vinyl, at a discounted rate compared to buying separately. Rega's unique pivot pad design eliminates the mechanical joint between the stylus housing and the main body for improved tracking and stability, and if the cartridge is ever damaged or worn, it can be returned to a Rega dealer for a rebuild fitted with a new cantilever, stylus, and pivot pad, each fully tested as a new cartridge. Every Rega product carries a Lifetime Limited Warranty.

Specifications

Frequently asked questions

What is the Rega Nd5?
The Rega Nd5 is a moving magnet phono cartridge developed over 10 years, believed to be among the first moving magnet cartridges to use an ultra-high-powered Neodymium N55 magnet. It pairs a nude elliptical diamond stylus and aluminium cantilever with new generator geometry and in-house-wound coils for a wide soundstage and highly detailed, accurate sound.

What is the difference between the Rega Nd5 and the Nd3?
Both use the Neodymium N55 magnet, the same generator and coil design, aluminium cantilever, and PPS body. The key difference is the stylus: the Nd5 has a nude elliptical diamond (a true ellipse for greater detail and tracking accuracy), while the Nd3 has a bonded elliptical diamond. The Nd5 is factory-fitted on the Planar 3 and Planar 6, and the Nd3 on the Planar 2 and Planar 3. The Nd5 is the higher-performing option.

What is a nude elliptical diamond stylus?
A nude stylus is a diamond that is a single piece rather than a small diamond tip bonded to a metal shank. The Nd5's nude elliptical diamond is a true ellipse formed by an elliptical grinding process, giving lower tip mass and more accurate contact with the groove for improved tracking and detail retrieval.

Which turntables is the Nd5 compatible with?
The Nd5 is a standard moving magnet cartridge suitable for turntables with a compatible tonearm and an MM phono stage. It is offered as a factory-fitted option on the Rega Planar 3 and Planar 6, and works with any MM phono input on a receiver, integrated amplifier, or standalone phono stage.

What happens if my Rega cartridge wears out?
Rega offers a rebuild scheme. Return the worn or damaged cartridge to your Rega dealer and receive a rebuild fitted with a new cantilever, stylus, and pivot pad, fully tested as a new cartridge, at a reduced price when you trade in the old one, comparable to a replacement stylus from other manufacturers.

Where can I buy the Rega Nd5 in Canada?
The Rega Nd5 is available at Vinyl Sound Canada with Canada-wide shipping. Order online or visit our showroom for fitting advice and turntable pairing recommendations.
