Teac AP701B Reference 700 Series Stereo Power Amplifier - Black
$3,999.99
Product Details
TEAC AP701B Reference 700 Series Stereo Power Amplifier, Fully Balanced Dual Mono Power
The TEAC AP701B is a fully balanced, dual mono stereo power amplifier from the Reference 700 Series, built around two proprietary Hypex Ncore power amplifier modules calibrated specifically for TEAC. From input to output, a complete dual mono structure with independent left and right high-capacity toroidal power transformers and discrete buffer amplifiers keeps the channels fully separated, magnifying the natural dynamism of the signal and drawing out the full performance of your speakers. In a low-profile black chassis, the AP701B is available now at Vinyl Sound in Canada.
Key Features
Two Hypex Ncore modules deliver high output with excellent efficiency, driving speakers cleanly from delicate pianissimo to forceful fortissimo. The complete dual mono layout achieves outstanding channel separation for a wide, three-dimensional soundstage. A 3mm-thick metal chassis with suspension joints and TEAC pin-point feet controls vibration, while a carefully engineered ventilation system and bottom-mounted modules allow a fan-free, low-noise design. Large linked VU meters, four dimmer levels, two sensitivity settings, bi-amp switching, and a 12V trigger in and through round out the feature set.
Technical Specifications
| Specification | Detail |
|---|---|
| Amplifier Type | Fully balanced dual mono, 2x Hypex Ncore modules |
| Practical Max Output | 260W + 260W (4 ohms), 170W + 170W (8 ohms), JEITA |
| Rated Output | 230W + 230W (4 ohms), 125W + 125W (8 ohms), THD 1% |
| Total Harmonic Distortion | 0.003% (8 ohms, 1kHz, 55W, JEITA) |
| S/N Ratio | 110 dB (8 ohms, 1kHz, IHF-A) |
| Frequency Response | 10Hz to 50,000Hz (+0dB, -6dB, 8 ohms, JEITA) |
| Balanced Input | XLR x 1 pair, 1.6V, 64k ohms (stereo) / 32k ohms (bi-amp) |
| Unbalanced Input | RCA gold-plated x 1 pair, 1.6V, 32k ohms (stereo) / 16k ohms (bi-amp) |
| Speaker Output | Gold screw type x 1 pair, banana compatible, 4 to 8 ohms |
| External Control | 12V trigger in and through, 3.5mm mono mini jack |
| Power | AC120V, 60Hz (US/Canada) |
| Power Consumption | 210W (0.4W standby) |
| Dimensions (W x H x D) | 444 x 111.3 x 348.2 mm (including protrusions) |
| Weight | 9.9 kg |
| Finish | Black |
| Included | Power cord, foot pad x3, owner's manual |
| SKU / UPC | AP701B / 043774034536 |
Why Buy from Vinyl Sound?
Vinyl Sound is an authorized Canadian dealer for TEAC. The AP701B comes with full manufacturer warranty and expert support from our team. We offer free ground shipping to all provinces in Canada, and our staff can help you match the AP701B to the right preamplifier and speakers for your system.
Frequently Asked Questions
Q: How much power does the TEAC AP701B deliver?
A: The AP701B delivers a practical maximum of 260W + 260W into 4 ohms and 170W + 170W into 8 ohms (JEITA), with a rated output of 230W + 230W (4 ohms) and 125W + 125W (8 ohms) at 1% THD. It is compatible with speakers from 4 to 8 ohms.
Q: Can the AP701B be used with balanced and unbalanced sources?
A: Yes. The AP701B has both balanced XLR and gold-plated unbalanced RCA inputs, each with 1.6V sensitivity. Its fully balanced input stage preserves signal clarity, and a bi-amp switch lets you configure the amplifier for bi-amping a single pair of speakers.
Q: Is the TEAC AP701B available in Canada?
A: Yes. The TEAC AP701B is available at Vinyl Sound, an authorized Canadian TEAC dealer, with free ground shipping to all provinces in Canada. You can also hear it in a system at our Toronto store.
