PRO-JECT - 6PERSPEX BALANCED SUPER PACK (PICK IT MC 3)

The 6PerspeX Balanced turntables uses a transparent acrylic plinth that stands on three height-adjustable TPE-damped aluminum cones. The plinth carries the outboard motor and sub-chassis. The sub-chassis (made of Corian) rests on opposing magnets forming a floating suspension for the record platter & tonearm. This sub-chassis suspension system staves off parasitic noise that sometimes accompanies conventional spring suspensions. A supplied spirit level allows for easy leveling of sub-chassis & record platter. The quiet-running AC motor unit drives the platter via the belt installed around the platter’s circumference. The motor incorporates an advanced DC-driven motor control that ensures speed stability and offers electronic toggling between 33 & 45rpm.

The resonance-optimized platter is a sandwich construction utilizing a precision-machined MDF plate coated 4mm thick in flat-ground recycled vinyl. A screw-down clamp & threaded spindle take the notion of ‘record coupling’ to the next level. The platter bearing is our  best design utilizing a stainless steel spindle topped with a ceramic ball. An inverted bronze bushing embedded in the underside of the platter rotates silently & smoothly. The headshell and armtube of the EVO 9 CC tonearm are fashioned from a single piece of carbon fiber. The conical armtube reduces standing wave reflections. The inverted tonearm bearing is comprised of four hardened stainless steel tips in ABEC-7-rated ball races.

You can order the 6PerspeX Balanced without a cartridge or with Pro-Ject’s Pick it MC3 moving coil. Supplied counterweights are suitable for cartridges between 5 & 14g to accommodate your preferred cartridge. Also supplied in the box is our Connect it Phono E RCA cable (with ground) – a semi-balanced, low-capacitance cable with superior shielding that’s optimized to carry the phono signal.

True Balanced – Get Blown Away

Setting us apart from the competition, all Pro-Ject turntables are configured for balanced operation.* Switching to balanced is no subtle upgrade and promises to redefine ‘reference’ sound quality in your turntable system. What’s needed to get there are a) a moving coil cartridge (Pick it Pro Balanced MM), b) a turntable with balanced phono outputs, c) a phono preamp with balanced phono inputs and d) a balanced cable carrying the phono signal from turntable to phono preamp. Typically a much more costly endeavor, Pro-Ject has changed that landscape by offering products that make the technology attainable to any serious listener.

6PerspeX Balanced comes equipped with 2 phono outputs: balanced mini XLR & RCA/ground. Balanced transmission is possible with either a mini XLR > mini XLR cable or with an RCA > Mini XLR cable. Either would connect to the mini XLR inputs of the following 3 phono preamps: Phono Box S3 B, Phono Box DS3 B or Tube Box DS3 B. The turntable ships with an RCA/ground > RCA/ground phono cable for maximum compatibility out of the box (unbalanced dual single-ended RCA/ground is by far the most common connection type in phono). Balanced add-ons are sold separately. Browse options for balanced phono preamps & cables in the reel below!

*Excluding turntables with built-in phono preamps.

Additional information

Features

• True Balanced Connection by Pro-Ject
• Balanced mini XLR output & RCA/ground output
• Optional factory-aligned Pick it MC3 phono cartridge
• Transparent acrylic plinth
• Magnetically suspended Corian sub-chassis (supports platter & tonearm)
• Acoustically inert vinyl-finished MDF record platter
• Threaded clamp couples records to vinyl/MDF platter
• Inverted main bearing with ceramic ball/plate
• Belt drive with DC-driven AC generator to AC motor
• Electronic speed regulation & 33/45rpm speed change
• EVO 9 CC tonearm w/ one-peice carbon fiber armtube
• Tonearm bearings with ABEC 7 quality ballraces
• Connect it Phono E RCA purpose-designed phono cables
• Handmade in Europe

Specs

6 PerspeX Balanced Turntable

• Speeds: 33 & 45rpm (electronic speed change)
• Drive principle: belt drive
• Platter: vinyl/MDF sandwich (300mm diameter)
• Main bearing: inverted stainless steel shaft, ceramic ball
• Wow & flutter: +/-0.1%
• Speed drift: +/-0.06%
• Signal to noise: 73dB
• Tonearm: EVO 9 CC w/ 1-piece 9″ carbon fiber armtube
• Effective arm length: 230mm
• Effective arm mass: 8.0g
• Overhang: 18mm
• Tracking force: 10-35mN (1.0-3.5g)
• Supplied counterweights: compatible w/ 5-14g carts
• External power supply: 15V DC 800mA
• Power connection: 110-120V 60 Hz (US)
• Power consumption: 6W max (<0.3W in standby)
• Dimensions (WxHxD): 460 x 183 x 365mm (18.1 x 7.2 x 14.4″)
• Weight: 11kg (24.3 lbs) net

Pick it MC3 Phono Cartridge

• Cartridge principle: moving coil (MC)
• Output voltage (1 kHz): 0.4mV (3.54cm/sec)
• Channel separation (1 kHz): 30dB
• Tracking ability (315Hz): 70μm
• Frequency response: 20Hz-20kHz (+/- 1dB)
• Stylus type: hyper-spherical
• Stylus tip radius: 5 x 250μm
• Tracking force range: 1.8-2.2g (18-22mN)
• Recommended tracking force: 2g (20mN)
• Tracking angle: 20°
• Recommended load resistance: 100-220Ω
• Break-in period: 30 hours
• Cartridge weight: 9.6g
